With a little TLC and straight-forward upkeep, you’ll be enjoying your Whaler for decades to come. Below you’ll find owner document downloads, maintenance guidance, and warranty information. If you can’t find what you’re looking for, view our FAQ Page, or contact our customer service team! We will respond as soon as possible, in the order your question is received. Monday through Friday, 8 a.m. – 5 p.m. EST. (Note: Please do not send duplicate questions, as this will add to response time)
For product information and dealer pricing, please contact your local Boston Whaler dealer. Pricing and parts are available through your nearest Boston Whaler dealership only.
Owner’s manuals, performance sheets, spec sheets, technical diagrams and prints. Below, you can sort by year, boat family and model for easy referencing.
Brush the canvas with a soft-bristled brush and hose down at regular intervals to remove dust, dirt, and environmental particles. It may be washed in a mild solution of natural soap (such as Ivory Flakes or Borateem) in lukewarm water (no more than 100 F). DO NOT use detergents. DO NOT allow the soap to dry. Rinse thoroughly with fresh water. Allow canvas to dry thoroughly. DO NOT PUT MARINE CANVAS IN WASHING MACHINE OR DRYER. Use of abrasive detergents and/or substrates containing solvents will damage the fabric and void the fabric warranty. Regular application of a fabric guard (such as 303 High Tech Fabric Guard) is recommended to ensure water and stain repellency.
WARNING: DO NOT clean chrome with harsh abrasives, scrub pads or stiff brushes, as this can damage the finish.
MIRAGE Hardwood Floor
The hardwood floor in the cabin can be kept clean and in good condition with routine cleaning.
FOR MORE INFORMATION, CONTACT THE TECHNICAL SERVICE DEPARTMENT AT 1-800-463-1303.
Corian brand Solid Surface Countertops: When properly cared for, your solid surface countertops will last a lifetime.
Routine Care: Soapy water, ammonia-based cleaners, or commercial solid surface cleaners, if used routinely, will remove most dirt and residue from the countertop.
Minor Cuts and Scratches: Rub the scratch in a straight line with a fine grit sandpaper periodically switch rubbing direction 90 degrees until all of the scratch is removed. Rinse top with water. Select the next lighter grit paper and rub over a large area to blend in the sanding. Continue the process using successively finer grits until desired gloss level is achieved. Wipe surface with damp cloth and let dry.
Heat Damage: Corian has excellent heat resistant properties. However, as with all countertop materials, it is important to minimize direct exposure to intense heat. We recommend the use of trivets or hot pads when placing hot objects on the countertop. Other Damage: In most cases Corian can be repaired if accidentally damaged. However, to prevent any permanent damage to your countertop avoid exposing the surface to strong chemicals, such as paint removers, oven cleaners, nail polish remover, etc. If contact occurs quickly flush the surface with water. Avoid cutting directly on the countertop.
Refurbishing: Over time and use your countertop may acquire a patina, changing the appearance of the finish. Using a general countertop polish rub the entire surface in a circular motion, rinse with clear water and wipe dry.
The cleaner your stainless trim and fittings can be kept, the greater the assurance of optimum corrosion resistance. Without proper care even the best stainless steel will corrode. Stainless steel is strong and corrosion resistant, but still requires maintenance to keep its appearance. Frequent routine cleaning of your stainless steel with mild soap water and cleaning wax will help maintain the finish.
Wash with mild soap and cold or lukewarm water.
DO NOT USE:
Even the finest cleaning powders can scratch or burnish a mill-rolled surface. On polished finishes, rubbing or wiping should be done in the direction of the polish lines, NOT across them. Crevice corrosion, a brownish coloring, occurs where two pieces of stainless hardware meet. This condition is caused by impurities in water and air and can be easily cleaned with a good grade marine polish using a sponge, cloth or small bristled brush (for nooks and crannies).
The teak features on your boat are constructed with natural teak which can withstand all climates and require little maintenance. Regularly wash your teak with a soft brush or sponge using soap and water. DO NOT use a steel brush or steel wool. DO NOT use high pressure cleaners. Avoid contact between strong solvents and caulk as it might be damage or dissolve caulk. Bleach can be used to get rid of darker spots in the surface layer. With fine grain sandpaper you can sand off the upper layer and get a smoother surface.
Based on preference, different surface treatments can be applied to your teak:
Refer to the manufacturer’s manual in your owner’s packet for complete instructions and warranty.
Care and Maintenance
Remove ordinary dirt and smudges with a mild soap and water solution. Dry with a soft, lint free cloth or towel. Allow the fabric to air dry in a well-ventilated area, preferably away from direct sunlight.
Mildew can occur if your boat does not have adequate ventilation. Heat alone will not prevent mildew; you must also provide fresh air circulation. To prevent mildew, keep the vinyl dry and make sure that moisture does not accumulate between the cushions.
Your cushions are not waterproof. They are constructed of open-cell foam and will absorb and hold water. Do not leave the cushions in standing water or exposed to heavy, prolonged rain. If, in the event your cushions become waterlogged, remove the foam from the cushion, press as much water as you can from the foam and allow to air dry.
What is “Pinking Cushions”?
Pinking is pink stain that is a by-product of a specific type of bacterial micro-organism. This microorganism produces a by-product, a dye, which is soluble in plasticizer (a primary ingredient in vinyl coated fabrics) and will stain any vinyl coated fabric it comes in contact with. Therefore, even a vinyl coated fabric that is properly protected with an anti-fungal agent will stain if the vinyl coated fabric comes in contact with the pink bacteria by-product.
The best protection against pink stain is to construct marine and outdoor seating and trim pieces in such as way as to reduce moisture and direct retention. Clean the upholstery thoroughly after each trip. If you’re not washing the boat, wipe down all the vinyl with a clean towel at the end of the day. Also, avoid the use of sunscreens containing PABA. It is recommended that boat owners cover their boats when not in use. Allow adequate venting to avoid trapping moisture to assist in reducing the adverse effect of continuous sunlight, which can degrade upholstery components over time and shorten the service life of exterior upholstery. Boat owners should refrain from stowing wet towels, all-weather gear, swimsuits, etc. inside their boats. Cabinets and lockers should be opened, if possible, to aid in air circulation. Moisture absorbing desiccants will aid in controlling interior moisture
Rinse windscreen thoroughly with clear water to remove any dust, dirt particles, salt water or environmental agents before applying cleaning products.
Use your bare hand, with plenty of water, to feel and dislodge any stuck – on dirt or foreign particles.
This should be done frequently to avoid build-up of salt water, dirt and other environmental contaminants.
Using a soft non-abrasive cloth, and applying only light pressure, wash windows inside and out with mild soap (Woolite, Joy, Palmolive, etc.) and water solution. Rinse completely with cool water.
Grease, oil, or tar may be removed with a good grade of hexane, aliphatic naptha, or kerosene. These solvents may be obtained at a paint or hardware store and should be used in accordance with manufacturer’s recommendations.
Blot dry with a soft cloth or chamois to prevent water spots.
The use of a polycarbonate protective cleaner/restorer is recommended to keep your acrylic scratch resistant, clean and minimize the deteriorating effects of sunlight.
Dusting should be done with a soft, damp cloth or chamois. Dry or gritty cloths may cause surface scratches and create a static electric charge on the surface. To avoid attracting dust due to electrostatic charges on the sheet, always clean with a damp cloth or with products made for such purposes, such as Plastiglas anti-static glaze.
Never use a dry cloth or duster or glass cleaning solutions on acrylic.
DO NOT USE solvents such as acetone’s, silicone spray, benzene, carbon tetrachloride, fire extinguisher fluid, dry cleaning fluid, lacquer thinner, glass cleaning solutions containing ammonia, or harsh detergents on acrylic. These can scratch the sheet’s acrylic surface and/or weaken the sheet causing small surface cracks called “crazing.”
Wash down completely with soap and fresh water and wipe dry after each use.
Wash completely using a soft cloth and mild detergent to remove salt particles. Hosing alone will not dislodge all particles. DO NOT allow soap to dry as it may cause stains on coated surface. Make sure to wash and dry full circumferences of bows (bimini and suntops).
Wash and apply an aluminum protectorant twice each year. Inspect and repair or replace all damaged nylon bushings, washers or other hardware deigned to prevent contact with dissimilar metals.
Whenever electrical or electronic changes are made to the boat, a qualified marine technician should check aluminum parts for stray currents. Make sure all electronic equipment is properly grounded with adequate sized wire.
Preventive maintenance is essential to life of the metals on your boat. The presence of salt particles and moisture is the major cause of white spots, pitting and corrosion. The use of harsh chemicals can also cause deterioration. Manufacturers and applicators of protective coatings will not warranty protective coatings on metals in the marine environment. Proper owner maintenance is required to reduce deterioration which will result in most cases by failure to wash down and wipe dry after each use and/or the use of abrasive, acidic or other improper cleaners.
Small touch ups can be made using white paint color RAL9010 or black paint color RAL 9005. Both are available from online resources in various quantities (spray paint, paint pens and touch up bottles)
From time to time, a slight algae or slime forms on all vessels. The bottom painted portion of the hull can be wiped off with a coarse Turkish towel or a piece of old rug while the boat is in the water. Do not use a stiff or abrasive material to clean the bottom paint. The bottom paint should be inspected annually. If it needs repainting, flush the old paint and wash with hot water and laundry detergent. Rinse well and let surface dry completely. Feather any deep scratches with sandpaper and repaint, following the directions on the bottom paint label. Replacement coating can be ordered from your Boston Whaler dealer. Fiberglass hulls should never be hauled, painted and relaunched the same day, since this does not allow sufficient time for the moisture which has been absorbed into the old paint film to completely dry out. Generally, 24 to 36 hours of drying time is required.
How to maintain, care for and repair your AwlGrip finished hull (model year 2012 – current):
For complete AwlGrip instructions, please refer to the following guidance: https://www.awlgrip.com/support/maintaining-an-awlgrip-finish
In summary –
Teflon is a registered trademark of E.I. du Pont de Nemours and Company.
How to maintain, care for and repair your DuPont Imron Marine Finish (model year 2004-2011):
DuPont Imron polyurethane enamels provide superior protection against elements that your boat will face throughout its long life. To make sure that you maximize the benefits of DuPont Imron, use the following guide to take care of your finish.
Should your boat’s finish become damaged, have it repaired as soon as possible. Contact a reputable repair shop near you and specify the DuPont Imron quality used for the original finish. This will assure you the best possible color match and the same durability and appearance as when your boat was new or newly
An inspection of the thru-hull fittings is recommended. Thru-hull fittings should be checked for proper seal annually and repaired as required. When the boat is in the water, the underwater fittings can be checked for dripping. It is recommended that the underwater fittings be removed, cleaned and resealed every other year.
Molded fiberglass with a gel coated exterior finish makes up the structure of the hull, deck and some interior parts of your Boston Whaler. The Gel Coat is the outer surface, often colored, that presents the shiny, smooth appearance which is associated with fiberglass products. In some areas, this Gel Coat surface is painted or taped for styling purposes. Wash the fiberglass regularly with clean, fresh water. Wax Gel Coated surfaces to maintain the luster. In northern climates, a semiannual waxing may suffice for the season. In southern climates, a quarterly application of wax will be required for adequate protection.
WARNING!: Gel Coat surfaces are slippery when wet. Use extreme care when walking on wet Gel Coat.
Recommended waxes are: 3M Perfect-it Gelcoat Boat Wax or Meguiars #26 Hiteck Yellow Wax. If the Gel Coated surface gloss cannot be restored by waxing, power buff with a rubbing compound such as 3M Super Duty #05955, followed with 3M Finesse-It 2 #05928 or 3M Imperial Hand Glaze #05990, then wax.
WARNING!: Care should be utilized in waxing commonly walked-upon areas of the boat to ensure that they are not dangerously slippery. An alternate method is to use Meguiars #44 Heavy Duty Color Restorer followed with Meguiars #50 Boat Cleaner/Polish, then wax. Recommended waxes are: 3M Perfect-it Gelcoat Boat Wax or Meguiars #26 Hiteck Yellow Wax. If Gel Coat is not maintained and becomes heavily oxidized, light sanding may be required before buffing.
If permanently moored in salt water or fresh water, your boat will collect marine growth on its bottom. This will detract from the boat’s beauty and greatly affect its performance.
There are two methods of preventing this:
Periodically haul the boat out of the water and scrub the bottom with a bristle brush and a solution of soap and water.
Paint the hull below the waterline with a good grade of antifouling paint. DO NOT paint the engine drive surfaces.
NOTE: There are EPA regulations regarding bottom paint application. Consult your Boston Whaler dealer for proper application methods.
Gel Coat and painted surfaces are very resistant to deep stains. Common surface stains can be removed with diluted household detergents, providing these detergents do not contain ammonia or chlorine. Porcelain-cleaning powders are too abrasive and often contain chlorine and ammonia, either of which would permanently discolor the Gel Coat and paint. Alcohol or kerosene can be used for difficult stains but should be washed away promptly with a mild detergent and water. Never use acetone or ketone solvents. Minor scratches and deeper stains which do not penetrate the Gel Coat may be removed by light sanding (or compounding) and buffing.
To protect your deck and non-skid areas from the deteriorating affects of the sun, oxidation, water spots and pollution, use a good quality “fiberglass and non-skid deck” wax every two to three months.
When applied to your deck and non-skid areas, as recommended by the manufacturer, the wax forms a protective non-slick surface which will keep debris from sticking. Dirt, soot, bird droppings, and even fish blood will rinse right off.
Propellers have two basic characteristics: diameter and pitch. Diameter is the distance in inches measured across the propeller hub line from the outer edge of the 360 that is made by the propeller’s blades during rotation. Pitch is the distance in inches that a propeller will travel if rotated one revolution without any slippage. For example, a propeller with a 12-inch pitch, when rotated 360 would, theoretically, advance 12 inches through the water. No 12-inch pitch blade will, in a single rotation, advance a boat 12 inches. This variance is referred to as slippage. When describing a propeller both the diameter and pitch are given. The diameter is referenced first and the pitch is second. Therefore, a 14″ x 19″ propeller would have a 14-inch diameter and a 19-inch blade pitch.
For questions regarding the correct prop or changing the prop on your engine, please contact the engine manufacturer.
Cavitation is a phenomenon that occurs in all propeller-driven craft under certain conditions. The surface of propeller blades is not perfectly flat, and as water is drawn through the blades to be discharged aft into the propeller’s slip stream, the water flowing over the curved surface of the blade encounters areas of greater and less pressure. In those areas of reduced pressure, air bubbles are formed. When they move out of the low pressure area, these bubbles collapse. If they collapse while in contact with an object, such as part of the propeller blade or a trim plane, the bubbles create such highly localized forces that they erode the surface of the object. In the case of the propeller, such damage is sometimes called a “burn.” It may be caused by an irregularity in the propeller’s leading edge, and should be corrected by reconditioning the propeller or by replacement. Cavitation is a normal occurrence in modern boats and propeller inspection should be a part of routine maintenance.
Propellers should be free of nicks, excessive pitting and any distortions that alter propellers from their original design. A badly damaged propeller should be replaced, but those that are chipped, bent or merely knocked out of shape can be reconditioned by your marine dealer. When doing extensive cruising, it is advisable to carry an extra propeller aboard. Operating your boat with a damaged propeller will reduce its top speed, may introduce undesirable handling characteristics and will definitely increase fuel consumption. A damaged propeller may also create unpleasant vibrations leading to an increased sound level. These excessive vibrations will hasten wear to rotating and reciprocating engine components and may cause costly damage.
Some of the more powerful motors create a considerable torque effect; that is, a twisting motion causing the boat to ride with one sheer lower than the other. This twisting reaction is caused by the direction of propeller rotation lifting one side of the boat. This causes uneven drag, so that the boat’s bow may tend to fall off in one direction or the other from the intended course given by the wheel. Outboard lower units are equipped with an adjustable trim tab which may be adjusted to balance “steering torque” so that the steering wheel will turn with equal ease in each direction. Follow the trim plane adjustment instructions in the Engine Owner’s Manual. Torque action may occur when maximum or close-to-maximum rated horsepower is applied. Any slight torque may be offset by shifting passenger or gear weight laterally to the high side of the boat.
While often called “cavitation”, ventilation is really a different effect. At times when a boat enters or leaves a sharp turn, the propeller seems to slip and lose thrust and the engine may over-speed. This problem is normally caused by air or aerated water entering the propeller. A damaged propeller can also cause ventilation. Ventilation can usually be corrected by one or more of the following:
Your Boston Whaler is equipped with propellers which our tests have shown to be the best suited for general use under normal conditions and load. In some situations, you may wish to change propellers to give your boat slightly different performance characteristics. In general, changing to a lower pitch propeller will increase acceleration and load-pulling ability, but with a slight decrease in top speed. Conversely, moving to a higher pitch propeller will attain higher top speed with a light load, but will sacrifice acceleration and power. Your particular requirements should be discussed with your Boston Whaler dealer.
UNDER NO CIRCUMSTANCES SHOULD YOU USE A PROPELLER WHICH ALLOWS THE ENGINE TO OPERATE AT A HIGHER THAN RECOMMENDED RPM.
Use only AGM (Absorbed Glass Mat) batteries with Verado engines.
Your batteries should always be enclosed in the battery trays provided with your boat and secured in place by the retaining lids. The trays will ensure that while underway the batteries will not move around, thus causing damage to components fitted in the same area.
Before use, check each battery and the charging system for loose connections or wiring.
Normal maintenance for ALL style batteries should include:
Pump the bilge dry and remove all loose dirt. Be sure that all limber holes are open. If there is oil in the bilge and the source is not known, look for leaks in engine oil lines or engine gaskets. Oil stains can be removed by using a bilge cleaner available from your dealer or a marina. DO NOT use flammable solvents.
Check all wiring to be sure it is properly supported; that its insulation is intact; and that there are no loose or corroded terminals. If there are corroded terminals, they should be replaced or thoroughly cleaned. Tighten all terminals securely and spray them with light marine preservative oil.
Inspect the entire fuel system (including fill lines and vents) for any evidence of leakage. Any stains around joints could indicate a leak. Try a wrench on all fittings to be sure they are not loose, but do not over-tighten them. Clean fuel filters and vent screen.
Inspect the entire bottom for evidence of seepage, damage or deterioration, paying particular attention to hull fittings, hoses and clamps. Straighten kinked hoses and replace any that do not feel pliable. Tighten loose hose clamps and replace those that are corroded. Tighten any loose nuts, bolts or screws.
Refer to your engine operator’s manual for engine maintenance details. Wipe off engines to remove accumulated dust and grease. If a solvent is used, make sure it is nonflammable. Go over the entire engine and tighten nuts, bolts and screws. Inspect the wiring on the engine and clean and tighten the terminals. Inspect the belts and tighten them if needed. Clean and lubricate the battery terminals; fill the battery cells with distilled water as needed.
Electrolysis corrosion of underwater metals on power boats can result in serious deterioration. The boat owner must be aware of the possibilities of galvanic action (the deterioration of underwater metals due to dissimilar characteristics when placed in salt water) and/or electrolysis. It is the owner’s responsibility to check for and replace damaged parts due to galvanic deterioration. Refer to your Boston Whaler dealer to investigate the source of stray corrosive currents. Inboard/outboard and outboard engines are fitted with zinc anodes on their lower units (refer to the engine operator’s manual for their locations). If your boat is equipped with trim planes (tabs), zinc plates are installed on the trim planes (tabs). Zinc protects underwater hardware. Zinc, being much less “noble” than copper-based alloys and aluminum used in Boston Whaler underwater fittings, will deteriorate first and protect the more noble parts. Zinc anodes generally require replacement about once a year. In salt water areas, replace every six months. The need to replace anodes more frequently may indicate a stray-current problem within the boat or at the slip or mooring. If zinc anodes do not need replacing after one year, they may not be providing proper protection. Loose anodes or low-grade zinc may be the problem. NOTICE: Do not paint between the zinc and metal it contacts and do not paint over the zinc.
When preparing to store a boat for extended periods of two months or more, it is best to make sure that the boat and its systems are properly conditioned for such extended periods of non-usage. The guidelines presented below give basic instructions on “winterizing” your boat and boat systems. If inexperienced with the process of winterization, it is best to hire the services of a professional.
In addition, always consult the owner’s manuals of the various systems and equipment on your boat for the manufacturer’s recommendations on winterizing and long term storage.
Protecting your engine’s vital moving parts from corrosion and rust caused by freezing of trapped water or excessive condensation due to climatic changes is very important. Freezing water in the engine can cause extensive damage to the internal moving parts. Internal engine parts can also be affected by rust due to lack of proper lubrication.
In addition, it is important that you follow all the recommendations set by the engine manufacturer’s operation manual.
Tank(s), hoses, and fuel pumps should be treated to help prevent the formation of varnish and gum. Temperature extremes will cause condensation to accumulate in an empty or partially filled fuel tank leading to fuel contamination and/or premature wear of your system. Fill the tank 95% full to allow for expansion, and add fuel stabilizer and conditioner, following the manufacturer’s recommendations, to provide fuel stability and corrosion protection.
Livewell/Raw Water System
Fresh Water System
If the water system will not be used for an extended amount of time, it is recommended that it be drained.
Winterizing the Mister System
If the system will not be in use, remove all the heads from the mister nozzles, clean them with CLR and store them. Do not replace them on the nozzles. Completely drain all water out of the system. Remove the mister lines from the pump. If the in-line filter will be usable when the mister system is put back into service, remove it from the system and store it in an area that will not freeze.
After Long Term Storage
Before you fill the freshwater system, it is vital that it be properly disinfected. The following procedure is recommended to disinfect the freshwater system:
Air Handling System
Follow manufacturer’s recommendations for winterization/long term storage. The manufacturer’s owner’s manual can be found in your owner’s manual packet.
Clean the deck with soap, hot water and a stiff brush to clean up any oil spills.
It is important to raise the bow of the boat enough to allow for proper drainage of water from the deck and bilge area. Make sure all the drainage fittings are clear and free of debris. Store the engine in an upright position to promote adequate drainage of water. Ensure that ALL drain plugs are removed (i.e. fishboxes, garboard drain, livewells, etc.)
When covering your boat, it is best to use a frame of either aluminum or wood to keep the cover up. This allows air to circulate and discourages water from pooling on the cover. Vents along the entire length of the cover will allow condensation to escape. Placing a series of foam pads between the hull and cover will also aid in air circulation and reduce condensation. To help keep your boat dry and mildew free, consider placing commercial odor and moisture absorbing products in the boat under the cover.
Antifreeze and other winterizing fluids can be toxic to aquatic life and cause harmful effects to plant life. Improper disposal or spillage of antifreeze and/or any winterization fluids can cause environmental problems when allowed to empty into waterways or on the ground. Furthermore, it is illegal, punishable at minimum by fines. Used antifreeze or any winterization fluids, should not be disposed of into sanitary sewers or publicly owned treatment plants. Persons who have any questions regarding recycling antifreeze or other toxic fluids should write or call their state’s EPA office.
Boston Whaler Parts and Accessories are available only through a Boston Whaler dealer. When contacting a Boston Whaler dealer regarding replacement parts, accessories, or service, please have all pertinent information such as serial numbers, model numbers, etc. on hand. Boston Whaler Boats, Inc. has a permanent record of your boat, which is retained under its “Hull Identification Number.” Data is kept regarding equipment and accessories, as well as dealer/shipping information. The “Hull Identification Number” (HIN), located on the starboard side of the transom, is the most important identifying factor and must be included in all correspondence and orders. Failure to include this information may cause shipment or service delays.
Boston Whaler does not recommend trailering with canvas or cushions installed. Secure these items inside the towing vehicle or a closed compartment within the boat. Damage (or loss) can occur to the canvas, cushion, or boat if installed on the boat while trailering.
Boston Whaler offers a 10-year Structural Hull Limited Warranty; a 3-year Limited Warranty on components manufactured or installed by Boston Whaler; and a 1-year Limited Warranty on upholstered items, canvas, teak and powder coating. Get the full details below:
